    Pulse Electronics PE-68280NLT

    Part No.:
    PE-68280NLT
    Manufacturer:
    Pulse Electronics
    Category:
    Current Sense Transformers
    Package:
    Datasheet:
    BomKey ElectronicsPE-68280NLT.pdf
    Description:
    CURR SENSE XFMR 1:1:100 SMD
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Related
    Attributes
    Property Value
    Manufacturer
    Pulse Electronics
    Series:
    PE-68XXXNL
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Frequency Range:
    50kHz ~ 500kHz
    Type:
    Invasive
    Current Rating (Amps):
    -
    Inductance:
    14.8 mH
    ET (Volt-Time):
    -
    Turns Ratio - Primary:Secondary:
    1:1:100
    Current Ratio:
    -
    DC Resistance (DCR):
    1.15mOhm Primary, 930mOhm Secondary
    Ratings:
    -
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.495" L x 0.490" W (12.57mm x 12.45mm)
    Height - Seated (Max):
    0.280" (7.11mm)
    Termination Style:
    -
    Category:
    Current Sense Transformers
