    Lite-On Inc. LSHD-5503

    Part No.:
    LSHD-5503
    Manufacturer:
    Lite-On Inc.
    Category:
    LED Character and Numeric
    Package:
    10-DIP (0.600", 15.24mm)
    Datasheet:
    BomKey ElectronicsLSHD-5503.pdf
    Description:
    DISPLAY 7SEG 0.56" SGL RED 10DIP
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Related
    Attributes
    Property Value
    Manufacturer
    Lite-On Inc.
    Series:
    -
    Package/Case:
    10-DIP (0.600", 15.24mm)
    Packaging:
    Tube
    Product Status:
    Active
    Display Format:
    -
    Number of Characters:
    1
    Size / Dimension:
    0.673" H x 0.488" W x 0.315" D (17.10mm x 12.40mm x 8.00mm)
    Digit/Alpha Size:
    0.56" (14.22mm)
    Display Type:
    7-Segment
    Common Pin:
    Common Cathode
    Color:
    Red
    Voltage - Forward (Vf) (Typ):
    2.1V
    Current - Test:
    20mA
    Millicandela Rating:
    17mcd
    Wavelength - Peak:
    632nm
    Power Dissipation (Max):
    70mW
    Category:
    LED Character and Numeric
