DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DC0602012U2B-2T0FAN AXIAL 60X20MM 12VDC WIRE |
2,557 |
|
Datasheet |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 20.00mm | 19.6 CFM (0.549m³/min) | 0.270 in H2O (67.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 33.0dB(A) | 2.04 W | 4800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.111 lb (50.35 g) |
|
CFM-8010-13-10FAN AXIAL 80X10.6MM 12VDC WIRE |
1,200 |
|
Datasheet |
CFM-80 | Tray | Obsolete | 12VDC | Square - 80mm L x 80mm H | 10.60mm | 33.6 CFM (0.941m³/min) | 0.110 in H2O (27.4 Pa) | Ball | Tubeaxial | Auto Restart | 38.2dB(A) | 2.88 W | 3300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.094 lb (42.64 g) |
|
CFM-8025V-148-447-11FAN AXIAL 80X25MM 12VDC WIRE |
1,327 |
|
Datasheet |
CFM-80V | Tray | Obsolete | 12VDC | Square - 80mm L x 80mm H | 25.00mm | 60.0 CFM (1.68m³/min) | 0.410 in H2O (102.1 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | Auto Restart | 44.7dB(A) | 4.29 W | 4800 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.165 lb (74.84 g) |
|
DC0702512L2B-2T0FAN AXIAL 70X25MM 12VDC WIRE |
2,037 |
|
Datasheet |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 25.00mm | 30.0 CFM (0.840m³/min) | 0.150 in H2O (37.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 27.0dB(A) | 840 mW | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.111 lb (50.35 g) |
|
CFM-A225B-120-350-20FAN AXIAL 120X25.4MM 12VDC WIRE |
1,206 |
|
Datasheet |
CFM-120B | Box | Active | 12VDC | Square - 120mm L x 120mm H | 25.40mm | 69.7 CFM (1.95m³/min) | 0.100 in H2O (24.9 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.8dB(A) | 2.76 W | 2000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-A225B-015-287-20FAN AXIAL 120X25.4MM 5VDC WIRE |
2,918 |
|
Datasheet |
CFM-120B | Box | Active | 5VDC | Square - 120mm L x 120mm H | 25.40mm | 52.2 CFM (1.46m³/min) | 0.060 in H2O (14.9 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 24.8dB(A) | 1.2 W | 1500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-4015B-2105-365-20DC AXIAL FAN, 40 MM SQUARE, 15 M |
1,970 |
|
Datasheet |
CFM-40B | Box | Active | 24VDC | Square - 40mm L x 40mm H | 15.10mm | 12.3 CFM (0.344m³/min) | 0.560 in H2O (139.5 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 36.5dB(A) | 2.64 W | 10500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
MC25101V2-000U-A99FAN AXIAL 25X10MM 12VDC WIRE |
4,100 |
|
Datasheet |
MagLev® MC | Tray | Obsolete | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 3.0 CFM (0.084m³/min) | 0.180 in H2O (44.8 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart | 16.0dB(A) | 450 mW | 10000 RPM | 2 Wire Leads | - | - | CE, CUR, TUV, UL | 0.017 lb (7.71 g) |
|
|
BFB0405MA-AFAN BLOWER 40X10MM 5VDC WIRE |
1,590 |
|
Datasheet |
BFB | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 10.00mm | 2.3 CFM (0.064m³/min) | 0.312 in H2O (77.7 Pa) | Ball | Blower | Locked Rotor Protection | 29.5dB(A) | 400 mW | 6500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.027 lb (12.25 g) |
|
|
MF30151V3-1000U-F9912VDC FAN 30X15MM TACH |
2,650 |
|
Datasheet |
MF | Box | Active | 12VDC | Square - 30mm L x 30mm H | 15.00mm | 2.7 CFM (0.076m³/min) | 0.050 in H2O (12.4 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart, Locked Rotor Sensor | 7.8dB(A) | 0.24 W | 4600 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
MF30151V2-1000U-F9912VDC FAN 30X15MM TACH |
3,480 |
|
Datasheet |
MF | Box | Active | 12VDC | Square - 30mm L x 30mm H | 15.00mm | 4.8 CFM (0.134m³/min) | 0.120 in H2O (29.9 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart, Locked Rotor Sensor | 19.0dB(A) | 0.42 W | 7000 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
MF30151V1-1000U-F9912VDC FAN 30X15MM TACH |
4,453 |
|
Datasheet |
MF | Box | Active | 12VDC | Square - 30mm L x 30mm H | 15.00mm | 6.0 CFM (0.168m³/min) | 0.170 in H2O (42.3 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart, Locked Rotor Sensor | 27.0dB(A) | 0.78 W | 9500 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
MC30150V1-000U-A99FAN AXIAL 30X15MM VAPO 5VDC WIRE |
2,822 |
|
Datasheet |
MagLev® MC | Bulk | Obsolete | 5VDC | Square - 30mm L x 30mm H | 15.00mm | 6.0 CFM (0.168m³/min) | 0.170 in H2O (42.3 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart | 27.0dB(A) | 570 mW | 8500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CUR, TUV, UL | 0.03 lb (13.61 g) |
|
|
DC0702512M2B-3T0FAN AXIAL 70X25MM 12VDC WIRE |
3,755 |
|
Datasheet |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 25.00mm | 35.6 CFM (0.997m³/min) | 0.220 in H2O (54.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 32.0dB(A) | 1.08 W | 3600 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.111 lb (50.35 g) |
|
|
DC0702512H2B-2T0FAN AXIAL 70X25MM 12VDC WIRE |
1,306 |
|
Datasheet |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 25.00mm | 39.9 CFM (1.12m³/min) | 0.270 in H2O (67.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 37.0dB(A) | 1.56 W | 4000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.111 lb (50.35 g) |
|
|
MF20100V2-1000U-S995VDC FAN 20X10MM TACH/PWM |
2,268 |
|
Datasheet |
MF | Box | Active | 5VDC | Square - 20mm L x 20mm H | 10.00mm | 1.5 CFM (0.042m³/min) | 0.200 in H2O (49.8 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 20.0dB(A) | 0.4 W | 14000 RPM | 4 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
MF20100V1-1000U-S995VDC FAN 20X10MM TACH/PWM |
2,420 |
|
Datasheet |
MF | Box | Active | 5VDC | Square - 20mm L x 20mm H | 10.00mm | 1.9 CFM (0.053m³/min) | 0.290 in H2O (72.2 Pa) | Vapo-Bearing™ | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.0dB(A) | 0.53 W | 16500 RPM | 4 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
19032710AFAN AXIAL 60X25MM CR0624HB-A70GL |
4,299 |
|
Datasheet |
Flight LT 60 | Bulk | Obsolete | 24VDC | Square - 60mm L x 60mm H | 25.00mm | 23.0 CFM (0.644m³/min) | 0.185 in H2O (46.1 Pa) | Ball | Tubeaxial | - | 32.3dB(A) | 3.6 W | 4500 RPM | 2 Wire Leads | - | - | CE, CSA, UR | 0.15 lb (68.04 g) |
|
CFM-A238S-226-435FAN AXIAL 120X37.5MM 24VDC WIRE |
1,233 |
|
Datasheet |
CFM-120S | Box | Active | 24VDC | Square - 120mm L x 120mm H | 37.50mm | 100.7 CFM (2.82m³/min) | 0.240 in H2O (59.8 Pa) | Sleeve | Tubeaxial | Auto Restart | 43.5dB(A) | 6.48 W | 2600 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
F6025L05B-RSFAN AXIAL 60X25MM BALL 5VDC WIRE |
4,268 |
|
Datasheet |
F6025 | Bulk | Obsolete | 5VDC | Square - 60mm L x 60mm H | 25.00mm | 14.0 CFM (0.392m³/min) | 0.140 in H2O (34.9 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Protection | 24.0dB(A) | - | 2800 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.139 lb (63.05 g) |
